TrueNAS Mini
TrueNAS Mini X+
TrueNAS Mini X+
Couldn't load pickup availability
The TrueNAS MINI X+ is a powerful, compact NAS solution built for professionals, home labs, and small businesses. Equipped with a multi-core processor and ECC memory, it ensures reliable performance and data integrity. Its quiet design and support for up to 5 hot-swappable drives make it ideal for environments where space and noise are concerns. The MINI X+ runs TrueNAS TrueNAS Community Edition, offering advanced ZFS features like snapshots, replication, and data compression. Whether you're managing backups, media libraries, or virtual machines, the MINI X+ delivers enterprise-class capabilities in a desktop-sized system.
Full Specifications
| FEATURES | TrueNAS Mini X+ |
| Chassis | 5+2 Bay Enclosure – Super Quiet Design |
| Drive Bays | 5 x SATA 3.5” Hot-Swappable Drive Bays |
| (Optional 3.5″ to 2.5″ adaptors available) | |
| 2 x SATA 2.5” Hot-Swappable SSD Bays | |
| Maximum Raw Capacity | Up to 105 TB |
| CPU | Octa-core C3758 Intel CPU |
| Memory | 32 GB DDR4 with ECC |
| (Upgradeable to 64GB) | |
| RAID | OpenZFS – RAIDZ1 (RAID 5), RAIDZ2 (RAID 6), Multi-Disk Mirror (RAID 10), and RAID0 (stripe) |
| Disk Management | Hot-Swappable Drives, Bad Block Scan + HDD S.M.A.R.T |
| ISO Mounting Support, Hardware-Accelerated Disk Encryption | |
| Network | Standard: 2 x RJ45 1/10GBaseT Ethernet LAN ports |
| Dedicated RJ45 IPMI Port (Remote Hardware Management) | |
| 2 x SFP+ 10G Add On Card (Optional) | |
| USB Ports | 1 x USB 3.0 Port (Front) |
| 1 x USB 2.0 Port (Front) | |
| 2 x USB 2.0 Ports (Rear) | |
| Read/Write Cache | (Optional) Boost performance by adding a dedicated, high-performance read cache (L2ARC) or by adding a dedicated, high-performance write cache (ZIL/SLOG) |
| PCIe Expansion | 1 x PCI Express 3.0 x 4 |
| Power Supply | 100V to 240V AC, 50/60 HZ, Single Phase |
| Power Consumption (Maximum) | Diskless: 40W |
| With drives & 10G Add-on-card: 111W | |
| Power Management | Remote Power-On/Off (IPMI), UPS Signal Response and Alerts |
| User Control Interface | Web Browser and Remote Hardware Management (IPMI) |
| Dimensions | 8.25″ x 10.5″ x 9.5″ / 210 x 267 x 241mm |
| (W x D x H) | |
| Weight | 13lbs / 5.9Kg |
| (no drives) | |
| Limited Warranty | 1-Year Warranty Included. Optional 3-Year Warranty purchasable. |
| Software Warranty requires registration at portal.ixsystems.com. | |
| Accessories | Basic Setup Guide, 2 x Case Door Keys, bag of HDD screws, 2 x 7 ft cat6 copper cable |
